1】沸石轉輪是一種吸附濃縮設備，他利用自身高吸附效率及脫附快的優勢把高風量低濃度濃縮濃度濃縮成低風量高濃度的有機廢氣，從而降低設備投資費用和運行成本實現經濟有機廢氣處理；

1】 Zeolite wheel is an adsorption concentration equipment that utilizes its advantages of high adsorption efficiency and fast desorption to concentrate high air volume and low concentration organic waste gas into low air volume and high concentration organic waste gas, thereby reducing equipment investment and operating costs to achieve economic organic waste gas treatment;

2】沸石轉輪與固定床相比較可實現吸附-脫附-冷卻連續運轉。由耐熱、耐腐蝕及耐磨性高的密封材料將沸石轉輪分隔為三部分即大扇形和二個小扇形部分；大扇形部分為吸附區，可吸附有機物；二個小扇形部分分別為冷卻區和高溫脫附區。

2】 Compared with fixed beds, zeolite wheels can achieve continuous operation of adsorption desorption cooling. The zeolite impeller is divided into three parts, namely a large fan-shaped part and two small fan-shaped parts, by sealing materials with high heat resistance, corrosion resistance, and wear resistance; The large fan-shaped part is an adsorption zone that can adsorb organic matter; The two small fan-shaped parts are the cooling zone and the high-temperature desorption zone, respectively.

沸石轉輪特征：

Characteristics of zeolite wheel:

1】沸石轉輪使用壽命長，可用5-10年；

1】 The zeolite wheel has a long service life and can be used for 5-10 years;

2】吸附VOCs所產生的壓降極低，降低了風機能耗；

2】 The pressure drop generated by adsorbing VOCs is extremely low, which reduces the energy consumption of the fan;

3】濃縮倍數數達5-30倍，節能高效，運行成本更低；

3】 The concentration factor can reach 5-30 times, which is energy-saving and efficient, with lower operating costs;

4】沸石轉輪采用蜂窩構造，更高的比表面積使用無機材料，具有不燃特征；

4】 The zeolite wheel adopts a honeycomb structure, with a higher specific surface area using inorganic materials and non combustible characteristics;

5】經過濃縮后的廢氣吸附效率高，吸附效率≥90%，高可達98%以上，可達到國家及地區排放標準。

5】 After concentration, the exhaust gas has a high adsorption efficiency, with an adsorption efficiency of ≥ 90% and can reach over 98%, which can meet national and regional emission standards.

綠緣環境沸石轉輪的優勢：

Advantages of Zeolite Wheel in Green Edge Environment:

【1】產品孔徑均勻，壓差穩定低于600帕，降低了轉輪堵孔的發生率；

【1】 The product has a uniform pore size and a stable pressure difference of less than 600 Pa, which reduces the occurrence rate of wheel blockage;

【2】特殊的燒結工藝，通過升溫曲線的控制，使轉輪模塊強度提升10%，吸附容量提高20%-30%，脫附時間縮短20%左右，極大地提高了轉輪的性能；

【2】 The special sintering process, through the control of the heating curve, increases the strength of the runner module by 10%, the adsorption capacity by 20% -30%, and the desorption time by about 20%, greatly improving the performance of the runner;

【3】提供與沸石轉輪搭配的預處理、末端燃燒工藝的全系統技術支持。

【3】 Provide comprehensive technical support for pre-treatment and end combustion processes in combination with zeolite wheels.
